DF Power DFPAK for Electric Vehicles

part number:
DFP500N120G1
Coming soon
$
55
Place order
Place order

About Product

Benefits

2x-3x power density improvement.

Very high current capability (500A)  with  4 high performance SiC dies in the smallest form factor.

50% system-level BOM  reduction with highly integrated package.

High reliability and longer life due via lower operating temperature.

Supports green production with carbon-neutral materials (e.g., Diamond Substrate).

Contact sales for dedicated volume pricing.

Product Specifications

  • Advanced SiC MOSFET with Single Crystal Diamond integration.
  • Best-in-class Rth < 0.059 °C/W and > 4.2kV isolation)
  • Lowest Rds(on) across the temperature range (< 4 mohm)
  • Superior switching performance via source sensing pin
  • High operating junction temperature (up to 200°C for 168 hrs)
  • RoHS Lead-free, AEC-Q100, and AQ324 Automotive Compliant
  • Applications: Traction Inverter, Industrial Drives, UPS
Contact sales for dedicated volume pricing.
